| Item | Details | Item | Details |
|---|---|---|---|
| Origin | Shandong, China | Brand Name | Jingfuyao |
| Product Name | MgO Board | Fire Rating | A1 Grade |
| Type | Fireproof Board | Size | 1200 × 2400 mm, customizable |
| Features | Fireproof, Moisture-Resistant | Thickness | 3–20 mm, customizable |
| Application | Wall panels, ceiling coverings | Colors | White, Grey, or customizable film-coated |
Tested by the National Fireproof Building Material Quality Supervision and Testing Center (NFTC), MgO Board achieves Class A non-combustible performance.
It offers excellent flame retardancy and is suitable for fire-rated wall systems, ceilings, and protective assemblies.
MgO Board maintains structural stability even in wet environments:
Dry bending strength: 15 MPa
Wet bending strength: 22 MPa
The board does not deform, swell, or deteriorate, making it ideal for kitchens, bathrooms, basements, and coastal climates.
Engineered with heat-resistant mineral materials, the board provides an effective thermal barrier with a thermal resistance rating of 1.14 m²·K/W.
This helps reduce heat transfer and improves the overall energy efficiency of wall and ceiling systems.
Certified by NFTC, MgO Board offers reliable sound insulation:
Wall system sound insulation rating: 44–47 dB
A 95 mm wall made with a 10 mm MgO Board creates one of the most effective lightweight sound-insulating partitions available in its class.
With a density below 1.0×10³ kg/m³, the board is lightweight yet structurally strong.
Its high bending strength and impact resistance:
Reduce material loss during handling
Improve installation efficiency
Save labor, space, and project costs
This makes MgO Board an ideal material for high-efficiency wall systems.
Supported by large-scale production capacity and advanced manufacturing technology, MgO Board offers strong cost competitiveness in international markets.
It is widely used in residential, commercial, industrial, and prefabricated construction projects globally.
External and internal wall panels
Ceiling systems
Fire-rated partitions and fireproof enclosures
Wet-area wall linings
Sound-insulating partitions
Prefabricated and modular buildings
Substrate for tiling, painting, or decorative finishes
